Portable Intelligent Counter-UAV System
$8,000.00
Man-Portable C-UAS Interception Tool for Individual Soldier Close-Range Low-Altitude Defense
Interceptor Vehicle Highlights
1. Light airframe and high thrust-to-weight propulsion system customized for low-altitude small aerial threats;
2. Coaxial calibration function to compensate boresight deviation and boost terminal collision accuracy;
3. 100-gram-class reserved payload space for integrating various terminal mission modules;
4. Expendable one-time-use design, unavailable for reuse after successful interception, dedicated to one-off neutralization of confirmed hostile targets.
Interceptor Vehicle Highlights
1. Light airframe and high thrust-to-weight propulsion system customized for low-altitude small aerial threats;
2. Coaxial calibration function to compensate boresight deviation and boost terminal collision accuracy;
3. 100-gram-class reserved payload space for integrating various terminal mission modules;
4. Expendable one-time-use design, unavailable for reuse after successful interception, dedicated to one-off neutralization of confirmed hostile targets.
Quantity
Add to cart
More Details
Overall System Advantages
- 10-Second Rapid Readiness The handheld platform adopts passive-operation and ergonomic design, which can shift from carry mode to launch-ready state within 10 seconds. It perfectly fits temporary deployment, mobile patrol and emergency response to sudden aerial targets.
- Direct Physical Contact Interception (Electromagnetic-Jam-Free) It neutralizes threats by physical collision between interceptor and target, independent of RF suppression or electronic jamming. Applicable to complex electromagnetic environments and areas where electromagnetic countermeasures are prohibited.
- High-Performance AI Visual Guidance The interceptor is equipped with built-in AI visual identification and small-target tracking modules, forming a full closed-loop workflow: target detection, locking, continuous tracking and terminal guidance, greatly lowering manual operation burden in terminal interception phase.
- Lightweight & High-Maneuverability Design The interceptor weighs only 850 grams with a high thrust-to-weight propulsion system, supporting rapid acceleration, flexible turning and real-time trajectory correction. It can intercept 10-inch/15-inch FPV drones and small fixed-wing aircraft.
- Optional Range-Aided Terminal Sensing An optional range sensor works with AI algorithms to output terminal trigger signals, improving the reliability of closed-loop physical interception.
- Independent Single-Soldier Closed-Loop Operation The individual operator version requires no connection to external radar, electro-optical or command platforms. It covers full on-site workflow: portable carriage, rapid emergency response, close-range neutralization, hit confirmation and video evidence recording.
Handheld Launch Platform Highlights
1. Ultra-light man-portable design: platform weight is about 1,150 g, suitable for long-duration carry and fast field deployment;
2. Passive power-free design: no external power supply or regular charging maintenance needed;
3. Ergonomic grip conforming to natural holding posture for fast aiming and real-time status check;
4. Dual mechanical & electrical safety interlock consisting of unlock button and launch trigger to avoid accidental firing;
5. High-brightness auxiliary aiming display for visual aiming assistance and real-time system status indication;
6. IP54 ingress protection rating for dust resistance and splash water resi
1. Ultra-light man-portable design: platform weight is about 1,150 g, suitable for long-duration carry and fast field deployment;
2. Passive power-free design: no external power supply or regular charging maintenance needed;
3. Ergonomic grip conforming to natural holding posture for fast aiming and real-time status check;
4. Dual mechanical & electrical safety interlock consisting of unlock button and launch trigger to avoid accidental firing;
5. High-brightness auxiliary aiming display for visual aiming assistance and real-time system status indication;
6. IP54 ingress protection rating for dust resistance and splash water resi
stance, adaptable to dusty and light rain outdoor conditions.
General Interception System Parameters
Parameter Specification
Neutralization Method Direct physical contact interception
Typical Engage Targets 10"/15" FPV drones, small fixed-wing aircraft
Max Level Flight Speed of Interceptor 450 km/h
Effective Engagement Range ≤250 m for 15-inch FPV; ≤600 m for fixed-wing aircraft with 3 m wingspan
Max Operational Radius ≤2.5 km
Max Flight Altitude ≤2 km
Transition Time (Carry to Launch Ready) ≤10 s
Terminal Interception Accuracy CEP ≤ 0.5 m
Max Wind Resistance Beaufort Level 6
Rain Adaptability Operable under light rain
Night Function Not equipped for single-soldier version
External System Compatibility No connection to external radar, EO or command platforms for individual version
Neutralization Method Direct physical contact interception
Typical Engage Targets 10"/15" FPV drones, small fixed-wing aircraft
Max Level Flight Speed of Interceptor 450 km/h
Effective Engagement Range ≤250 m for 15-inch FPV; ≤600 m for fixed-wing aircraft with 3 m wingspan
Max Operational Radius ≤2.5 km
Max Flight Altitude ≤2 km
Transition Time (Carry to Launch Ready) ≤10 s
Terminal Interception Accuracy CEP ≤ 0.5 m
Max Wind Resistance Beaufort Level 6
Rain Adaptability Operable under light rain
Night Function Not equipped for single-soldier version
External System Compatibility No connection to external radar, EO or command platforms for individual version
Interceptor Vehicle Parameters
Parameter Specification
Total Weight 850 g
Overall Dimensions 170 × 170 × 330 mm
Wheelbase / Wingspan 230 mm / 180 mm
Battery Spec 1400 – 1850 mAh lithium-ion battery
Full Charging Time ≤ 0.5 h
Payload Capacity 100-gram class
Guidance Mode High-performance AI visual guidance
Terminal Sensing Solution Pure vision or optional range sensor assistance
Navigation Auxiliary GNSS-assisted return-to-home function
Recording Module VTX video transmission recorder for mission archive & post-operation debrief
Reusability Non-reusable after effective interception
Total Weight 850 g
Overall Dimensions 170 × 170 × 330 mm
Wheelbase / Wingspan 230 mm / 180 mm
Battery Spec 1400 – 1850 mAh lithium-ion battery
Full Charging Time ≤ 0.5 h
Payload Capacity 100-gram class
Guidance Mode High-performance AI visual guidance
Terminal Sensing Solution Pure vision or optional range sensor assistance
Navigation Auxiliary GNSS-assisted return-to-home function
Recording Module VTX video transmission recorder for mission archive & post-operation debrief
Reusability Non-reusable after effective interception
Handheld Launch Platform Parameters
Parameter Specification
Product Form Handgun-style handheld launcher
Overall Dimensions 270 × 260 × 145 mm
Platform Weight 1,150 g
Power Supply Mode Passive power-free design, no charging required
Ingress Protection Grade IP54
Product Form Handgun-style handheld launcher
Overall Dimensions 270 × 260 × 145 mm
Platform Weight 1,150 g
Power Supply Mode Passive power-free design, no charging required
Ingress Protection Grade IP54
Target Identification & Stable Lock-On Distance (Target: Fixed-wing aircraft with 2.8 m wingspan)
Environmental Condition Identification Range Stable Lock-On Range Remarks
Daytime Normal Illumination 250 – 500 m 150 – 400 m Clear background, unobstructed, good visibility
Daytime Backlight 150 – 400 m 150 – 350 m Performance affected by sun angle, target silhouette & background contrast
Light Rain Weather 150 – 400 m 150 – 350 m Valid under light rain without heavy mist or vapor obstruction
Daytime Normal Illumination 250 – 500 m 150 – 400 m Clear background, unobstructed, good visibility
Daytime Backlight 150 – 400 m 150 – 350 m Performance affected by sun angle, target silhouette & background contrast
Light Rain Weather 150 – 400 m 150 – 350 m Valid under light rain without heavy mist or vapor obstruction
Applicable Target Speed Range
10-inch FPV drone: 60 – 120 km/h
15-inch FPV drone: 70 – 120 km/h
Small fixed-wing aircraft: 60 – 120 km/h
10-inch FPV drone: 60 – 120 km/h
15-inch FPV drone: 70 – 120 km/h
Small fixed-wing aircraft: 60 – 120 km/h
Reference Single-Shot Interception Success Rate
10-inch FPV drone, engagement range 50–200 m: ≥75% under Beaufort 0–3; ≥50% under Beaufort 4–6
15-inch FPV drone, engagement range 50–200 m: ≥70% under Beaufort 0–3; ≥60% under Beaufort 4–6
Small fixed-wing aircraft, engagement range 50–500 m: ≥75% under Beaufort 0–3; ≥50% under Beaufort 4–6
Environmental Adaptability Index
Item Parameter Remarks
Max Wind Resistance Beaufort Scale 6 Interception efficiency varies with target mobility & gusts
Light Rain Operation Standard Precipitation ≤ 2.5 mm/h Test benchmark
Operating Temperature -10 °C ~ +45 °C Preheating recommended for low-temperature missions to stabilize battery performance
Storage Temperature -20 °C ~ +60 °C Avoid long-time high-temperature storage & direct sunlight exposure
Operating Humidity 20% – 95% RH (Non-condensing) Separate verification required for condensation, salt spray & heavy fog environments
Max Wind Resistance Beaufort Scale 6 Interception efficiency varies with target mobility & gusts
Light Rain Operation Standard Precipitation ≤ 2.5 mm/h Test benchmark
Operating Temperature -10 °C ~ +45 °C Preheating recommended for low-temperature missions to stabilize battery performance
Storage Temperature -20 °C ~ +60 °C Avoid long-time high-temperature storage & direct sunlight exposure
Operating Humidity 20% – 95% RH (Non-condensing) Separate verification required for condensation, salt spray & heavy fog environments
Safety Mechanisms
1. Dual mechanical & electrical unlock interlock to prevent accidental trigger;
2. Mandatory manual launch confirmation, maintaining human-in-the-loop control throughout operation;
3. Built-In Self-Test (BIT): pre-launch inspection for interceptor connection, battery health, sensor status and platform readiness;
4. Automatic lockback upon unlock timeout; firing disabled if readiness conditions are unmet;
5. Complete mission log storage: recording device ID, timestamp, system status code, launch & lock status, interception result;
6. Independent training mode with simulated launch workflow for operator familiarization;
7. Optional training interceptors to cut training cost and reduce consumable loss.
1. Dual mechanical & electrical unlock interlock to prevent accidental trigger;
2. Mandatory manual launch confirmation, maintaining human-in-the-loop control throughout operation;
3. Built-In Self-Test (BIT): pre-launch inspection for interceptor connection, battery health, sensor status and platform readiness;
4. Automatic lockback upon unlock timeout; firing disabled if readiness conditions are unmet;
5. Complete mission log storage: recording device ID, timestamp, system status code, launch & lock status, interception result;
6. Independent training mode with simulated launch workflow for operator familiarization;
7. Optional training interceptors to cut training cost and reduce consumable loss.
Typical Application Scenarios
1. Low-Altitude Security for Temporary Large-Scale Events
Short-term deployment for sports matches, exhibitions and mass gatherings, providing patrol security staff with portable close-range UAV neutralization equipment.
2. Perimeter Protection of Critical Infrastructure
Low-altitude patrol for energy plants, chemical factories, power stations, warehouses and ports, acting as a mobile supplementary solution to fixed counter-UAV systems.
3. Mobile Patrol for Campuses & Military Bases
Mobile inspection in schools, military camps, training grounds and temporary field outposts, improving rapid response capability against sudden low-altitude drone threats.
4. Threat Disposal in Electromagnetically Restricted Zones
Physical collision interception serves as an alternative neutralization method in areas where RF jamming and electromagnetic suppression are forbidden.
