HWDJ-13 Brushless DC Coreless Motor
$500.00
Brushless DC coreless motors eliminate iron loss and cogging torque thanks to coreless winding structure. Featuring ultra-low inertia, fast dynamic response, smooth torque output and high efficiency, these motors deliver precise speed and position control. Without magnetic cogging effect, they operate quietly with minimal vibration. Customizable voltage, power and installation dimensions are available, widely applied in servo actuation systems, precision testing equipment, airborne devices and optical stabilization platforms.
Quantity
Add to cart
More Details
Application
Power source for a certain micro gear pump.
Structure Form
Shielded motor;Split-type motor structure;Internal liquid cooling with RP-3 aviation jet fuel;Motor inner cavity withstand pressure ≤1.5 MPa, zero leakage.
Main Technical Specifications
Rated Voltage: 12 VDC
Rated Speed: 12500 rpm
Rated Torque: 0.035 N·m
Motor Efficiency: ≥62%
Speed Adjustment Range: 1000 rpm ~ 13000 rpm
Speed Control: Sensorless Control
Rotation Direction: Counterclockwise when facing the output shaft
Maximum Output Torque: ≥0.1 N·m
Operating Conditions
Operating Temperature: (-45 ~ +60) °C;
Operating Altitude: (0 ~ 15000) m.
